| Part number: | 106M |
| Description: | AUDIO XFMR 20K / 2KCT TH |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 1.080" L x 0.880" W (27.43mm x 22.35mm) |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Transformer Type | Miniature Epoxy Potted |
| Insertion Loss | 1dB |
| Frequency Range | 215Hz |
| Voltage - Isolation | 200V |
| Height - Seated (Max) | 0.950" (24.13mm) |
| Impedance - Primary (Ohms) | 20k |
| Impedance - Secondary (Ohms) | 2kCT |
| DC Resistance (DCR) - Primary | 1.18kOhm |
| DC Resistance (DCR) - Secondary | 89Ohm |
| Frequency Response | -1dB |
| Power Level | 150mW |
|
