| Part number: | 106S |
| Description: | AUDIO XFMR 100CT / 3.2 TH |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 1.080" L x 0.880" W (27.43mm x 22.35mm) |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Transformer Type | Miniature Epoxy Potted |
| Insertion Loss | 1dB |
| Frequency Range | 170Hz |
| Voltage - Isolation | 200V |
| Height - Seated (Max) | 0.950" (24.13mm) |
| Impedance - Primary (Ohms) | 100CT |
| Impedance - Secondary (Ohms) | 3.2 |
| DC Resistance (DCR) - Primary | 4.4Ohm |
| DC Resistance (DCR) - Secondary | 300mOhm |
| Frequency Response | -1dB |
| Power Level | 1.5W |
|
