| Part number: | 291AEX |
| Description: | PWR XFMR LAMINATED CHAS MT |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Box |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 63.50mm L x 71.55mm W |
| Mounting Type | Chassis Mount |
| Type | Laminated Core |
| Weight | 3 lbs (1.4 kg) |
| Termination Style | Wire Leads |
| Primary Winding(s) | Dual, Multiple Taps |
| Secondary Winding(s) | Triple |
| Current - Output (Max) | 100mA, 2.25A, 3A |
| Voltage - Primary | 100V, 110V, 120V, 210V, 220V, 230V, 240V |
| Height - Seated (Max) | 77.80mm |
| Voltage - Secondary (Full Load) | 650V, 6.3V, 5V |
| Center Tap | Yes |
|
