| Part number: | 744114 |
| Description: | FIXED IND 127UH 2.3A 120 MOHM TH |
| Manufacturer | Würth Elektronik Midcom |
| Encapsulation | Bulk |
| Quantity | 200 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Würth Elektronik Midcom" |
| Tolerance | ±20% |
| Package / Case | Radial, Vertical (Open) |
| Size / Dimension | 0.709" Dia x 0.354" W (18.00mm x 9.00mm) |
| Mounting Type | Through Hole |
| Shielding | Unshielded |
| Type | Toroidal |
| Operating Temperature | -40°C ~ 105°C |
| DC Resistance (DCR) | 120mOhm Max |
| Frequency - Self Resonant | 4.8MHz |
| Current - Saturation (Isat) | 1A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 10 kHz |
| Inductance | 127 µH |
| Current Rating (Amps) | 2.3 A |
|
