| Part number: | 744107 |
| Description: | FIXED IND 557UH 1.1A 700 MOHM TH |
| Manufacturer | Würth Elektronik Midcom |
| Encapsulation | Bulk |
| Quantity | 40 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Würth Elektronik Midcom" |
| Tolerance | ±20% |
| Package / Case | Radial, Vertical (Open) |
| Size / Dimension | 0.886" Dia x 0.472" W (22.50mm x 12.00mm) |
| Mounting Type | Through Hole |
| Shielding | Unshielded |
| Type | Toroidal |
| Operating Temperature | -40°C ~ 105°C |
| DC Resistance (DCR) | 700mOhm Max |
| Frequency - Self Resonant | 2.5MHz |
| Current - Saturation (Isat) | 700mA |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 10 kHz |
| Inductance | 557 µH |
| Current Rating (Amps) | 1.1 A |
|
