| Part number: | NCP13992CBDR2G |
| Description: | HIGH PERF CURRENT MODE RESONANT |
| Manufacturer | Sanyo Semiconductor/onsemi |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 2500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Sanyo Semiconductor/onsemi" |
| Package / Case | 16-SOIC (0.154", 3.90mm Width), 14 Leads |
| Mounting Type | Surface Mount |
| Operating Temperature | -50°C ~ 150°C (TJ) |
| Duty Cycle | 50% |
| Frequency - Switching | 20kHz ~ 750kHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | 600V |
| Output Isolation | Isolated |
| Topology | Flyback, Secondary Side SR |
| Voltage - Supply (Vcc/Vdd) | 9.5V ~ 20V |
| Supplier Device Package | 16-SOIC |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit, UVLO |
| Voltage - Start Up | 11.9 V |
| Control Features | Frequency Control, Soft Start |
|
