TYPE	DESCRIPTION
Mfr	"Nichicon"
Tolerance	±10%
Package / Case	Radial - 4 Leads
Mounting Type	Through Hole
Operating Temperature	-40°C ~ 85°C
Applications	DC Link, DC Filtering; High Frequency, Switching
Lead Spacing	2.067" (52.50mm)
Termination	PC Pins
Dielectric Material	Polypropylene (PP), Metallized
Voltage Rating - DC	700V
Height - Seated (Max)	1.772" (45.00mm)
Capacitance	40 µF
ESR (Equivalent Series Resistance)	3.8 mOhms
Size / Dimension	2.264" L x 1.181" W (57.50mm x 30.00mm)
