| Part number: | VVZ110-12IO7 |
| Description: | RECT BRIDGE 3PH 110A 1200V PWSE2 |
| Manufacturer | Littelfuse / IXYS RF |
| Encapsulation | Box |
| Quantity | 5 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Littelfuse / IXYS RF" |
| Package / Case | PWS-E2 |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Structure | Bridge, 3-Phase - SCRs/Diodes |
| Current - Hold (Ih) (Max) | 200 mA |
| Current - Gate Trigger (Igt) (Max) | 100 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 1150A, 1230A |
| Number of SCRs, Diodes | 3 SCRs, 3 Diodes |
| Current - On State (It (AV)) (Max) | 110 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5 V |
| Current - On State (It (RMS)) (Max) | 58 A |
| Voltage - Off State | 1.2 kV |
|
