| Part number: | VTO175-14IO7 |
| Description: | RECT BRIDGE 3PH 1400V PWS-E-2 |
| Manufacturer | Littelfuse / IXYS RF |
| Encapsulation | Box |
| Quantity | 5 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Littelfuse / IXYS RF" |
| Package / Case | PWS-E2 |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Structure | Bridge, 3-Phase - All SCRs |
| Current - Hold (Ih) (Max) | 200 mA |
| Current - Gate Trigger (Igt) (Max) | 100 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 1500A, 1600A |
| Number of SCRs, Diodes | 6 SCRs |
| Current - On State (It (AV)) (Max) | 167 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5 V |
| Current - On State (It (RMS)) (Max) | 89 A |
| Voltage - Off State | 1.4 kV |
|
