| Part number: | PCSV65-1R0T-RC |
| Description: | 1.0H 30% SMD SHIELDED POWER CHIP |
| Manufacturer | Allied Components International |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Allied Components International" |
| Tolerance | ±30% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.236" L x 0.236" W (6.00mm x 6.00mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| DC Resistance (DCR) | 12mOhm |
| Current - Saturation (Isat) | 12.2A |
| Inductance Frequency - Test | 100 kHz |
| Height - Seated (Max) | 0.177" (4.50mm) |
| Inductance | 1 µH |
| Current Rating (Amps) | 6.5 A |
|
