| Part number: | 4448R-20L |
| Description: | INDUCT ARRAY 2 COIL 25UH SMD |
| Manufacturer | API Delevan |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 50 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "API Delevan" |
| Tolerance | ±15% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.530" L x 0.530" W (13.46mm x 13.46mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Operating Temperature | -55°C ~ 125°C |
| Height | 0.310" (7.87mm) |
| Number of Coils | 2 |
| Inductance - Connected In Series | 100 µH |
| Inductance - Connected In Parallel | 25 µH |
| Current Rating - Parallel | 1.6 A |
| Current Rating - Series | 800 mA |
| DC Resistance (DCR) - Parallel | 116mOhm Max |
| DC Resistance (DCR) - Series | 464mOhm Max |
|
