| Part number: | PCHC1265HP-R33M |
| Description: | 0.33H 20% POWER CHOKE HIGH CURRE |
| Manufacturer | Allied Components International |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Allied Components International" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.531" L x 0.492" W (13.50mm x 12.50mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -40°C ~ 125°C |
| DC Resistance (DCR) | 0.8mOhm Max |
| Current - Saturation (Isat) | 68A |
| Inductance Frequency - Test | 100 kHz |
| Height - Seated (Max) | 0.256" (6.50mm) |
| Inductance | 330 nH |
| Current Rating (Amps) | 46 A |
|
