| Part number: | CMLB051H-3R3MS |
| Description: | FIXED IND 3.3UH 4.7A 52MOHM SMD |
| Manufacturer | Delta Electronics / Cyntec |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Delta Electronics / Cyntec" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.213" L x 0.205" W (5.40mm x 5.20mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 52mOhm Max |
| Current - Saturation (Isat) | 4.8A |
| Material - Core | Metal |
| Inductance Frequency - Test | 100 kHz |
| Height - Seated (Max) | 0.071" (1.80mm) |
| Inductance | 3.3 µH |
| Current Rating (Amps) | 4.7 A |
|
