| Part number: | ALF20C102EL450 |
| Description: | CAP ALUM 1000UF 20% 450V PRESS |
| Manufacturer | TOKIN (KEMET) |
| Encapsulation | Bulk |
| Quantity | 36 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "TOKIN (KEMET)" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - Press-Fit - 4 Lead |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole, Press-Fit |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | 0.886" (22.50mm) |
| ESR (Equivalent Series Resistance) | 114mOhm @ 100Hz |
| Lifetime @ Temp. | 18000 Hrs @ 85°C |
| Height - Seated (Max) | 3.228" (82.00mm) |
| Capacitance | 1000 µF |
| Voltage - Rated | 450 V |
| Ripple Current @ Low Frequency | 4.95 A @ 100 Hz |
| Ripple Current @ High Frequency | 9.32 A @ 10 kHz |
|
