| Part number: | BZX84-C5V6/DG/B4R |
| Description: | DIODE ZENER 5.6V 250MW TO236AB |
| Manufacturer | Nexperia |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nexperia" |
| Tolerance | ±5% |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Voltage - Zener (Nom) (Vz) | 5.6 V |
| Impedance (Max) (Zzt) | 40 Ohms |
| Supplier Device Package | TO-236AB |
| Grade | Automotive |
| Power - Max | 250 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 1 µA @ 2 V |
| Qualification | AEC-Q101 |
|
