| Part number: | 929836-01-16-RK |
| Description: | CONN HEADER VERT 32POS 2.54MM |
| Manufacturer | 3M |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "3M" |
| Connector Type | Header |
| Current Rating (Amps) | 2.5A |
| Mounting Type | Through Hole |
| Number of Positions | 32 |
| Number of Rows | 2 |
| Style | Board to Board |
| Operating Temperature | -40°C ~ 105°C |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Copper Alloy |
| Insulation Color | Black |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | 200.0µin (5.08µm) |
| Contact Finish - Post | Tin |
| Contact Shape | Square |
| Contact Length - Post | 0.110" (2.79mm) |
| Insulation Height | 0.100" (2.54mm) |
| Shrouding | Unshrouded |
| Overall Contact Length | 0.445" (11.30mm) |
| Insulation Material | Polycyclohexylenedimethylene Terephthalate (PCT) |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Contact Length - Mating | 0.235" (5.97mm) |
|
