| Part number: | SDH15P |
| Description: | CONNECTOR HD15M SOLDER |
| Manufacturer | L-com |
| Encapsulation | Bag |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "L-com" |
| Features | Grounding Indents |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Current Rating (Amps) | 1A |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 22 AWG |
| Number of Positions | 15 |
| Number of Rows | 3 |
| Operating Temperature | -55°C ~ 105°C |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (Unthreaded) |
| Termination | Solder Cup |
| Connector Style | D-Sub, High Density |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Dielectric Material | Thermoplastic |
| Shell Material, Finish | Steel, Tin-Nickel Plated |
| Contact Material | Brass |
| Shell Size, Connector Layout | 1 (DE, E) High Density |
| Primary Material | Metal |
|
