| Part number: | LI150-20B48PR2 |
| Description: | AC/DC DIN RAIL SUPPLY 48V 154W |
| Manufacturer | Mornsun |
| Encapsulation | Box |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Mornsun" |
| Power (Watts) | 154W |
| Features | Adjustable Output, Universal Input |
| Size / Dimension | 2.28" L x 4.13" W x 3.54" H (58.0mm x 105.0mm x 90.0mm) |
| Operating Temperature | -30°C ~ 70°C (With Derating) |
| Applications | Household Appliances, ITE (Commercial) |
| Input Type | AC or DC |
| Approval Agency | CE, EN |
| Efficiency | 91% |
| Current - Output (Max) | 3.2A |
| Voltage - Output 1 | 48V |
| Minimum Load Required | No |
| Number of Outputs | 1 |
| Voltage - Isolation | 4 kV |
| Standard Number | 60335-1; 62368-1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | 120V |
| DC Voltage - Input (Max) | 370V |
|
