| Part number: | SVB050M101GABPE50V00A |
| Description: | CAP ALUM 100UF 20% 50V SMD |
| Manufacturer | Suscon |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Suscon" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Applications | Automotive |
| Ratings | AEC-Q200 |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Capacitance | 100 µF |
| Voltage - Rated | 50 V |
| Ripple Current @ Low Frequency | 160 mA @ 100 Hz |
| Ripple Current @ High Frequency | 1.6 A @ 100 kHz |
|
