| Part number: | CD035M150D06PE50V00A |
| Description: | CAP ALUM 15UF 20% 35V SMD |
| Manufacturer | Suscon |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Suscon" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Polarization | Polar |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 105°C |
| Applications | Automotive |
| Ratings | AEC-Q200 |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Surface Mount Land Size | 0.209" L x 0.209" W (5.30mm x 5.30mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Capacitance | 15 µF |
| Voltage - Rated | 35 V |
| Impedance | 760 mOhms |
| Ripple Current @ Low Frequency | 52.5 mA @ 120 Hz |
| Ripple Current @ High Frequency | 150 mA @ 100 kHz |
|
