| Part number: | CS035M221G10PE50V00A |
| Description: | CAP ALUM 220UF 20% 35V SMD |
| Manufacturer | Suscon |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Suscon" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Polarization | Polar |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 85°C |
| Applications | Automotive |
| Ratings | AEC-Q200 |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Capacitance | 220 µF |
| Voltage - Rated | 35 V |
| Ripple Current @ Low Frequency | 570 mA @ 120 Hz |
| Ripple Current @ High Frequency | 855 mA @ 10 kHz |
|
