| Part number: | UH100M100F12PE50P50A |
| Description: | CAP ALUM 10UF 20% 100V RADIAL TH |
| Manufacturer | Suscon |
| Encapsulation | Bulk |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Suscon" |
| Tolerance | ±20% |
| Package / Case | Radial, Can |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 130°C |
| Applications | Automotive |
| Lead Spacing | 0.138" (3.50mm) |
| Ratings | AEC-Q200 |
| Lifetime @ Temp. | 2000 Hrs @ 130°C |
| Height - Seated (Max) | 0.472" (12.00mm) |
| Capacitance | 10 µF |
| Voltage - Rated | 100 V |
| Impedance | 1 Ohms |
| Ripple Current @ Low Frequency | 140 mA @ 120 Hz |
| Ripple Current @ High Frequency | 200 mA @ 100 kHz |
|
